Grass Elite Plus 16 (max 5/8") Full Extension Soft Close Undermount Drawer Slide - 9-7/16" - 13132-03

Product Description
- Zinc plated, roll formed steel components
- Precision, smooth-running synthetic roller carriages
- Liquid damper softly glides drawers to a stop
- Self-latching front locking devices have comfortable release levers for drawer removal and installation
- Full extension
- Height adjustment +2.5mm (3/32") with suitable front locking device
- Side adjustment ±1.5mm (1/16") with suitable front locking device
- Positive tracked right side, ± 1.5mm (1/16") side tolerance on left side
- Self-closing mechanism engages 30mm (1 1/4") before closed position
- Weight capacity: 75 lb dynamic, 100 lb static
- Meets and exceeds ANSI/BHMA A156.9 Standard, Grade 1

- Drawer length: 9-7/16" (240mm)
- Nominal length: 9-27/32" (250mm)
- Min installation depth: 10-3/16" (259mm)
- Manufacturer Item No.: 13132-03
- Sold: Pair (left & right included)
- Locking devices sold separately
Sku: 13132-03
Vendor: Grass
$20.24
